| CARACTERISTICI HARDWARE | |
|---|---|
| Interfață | • 5× 10/100/1000Mbps RJ45 Ports • AUTO Negotiation • AUTO MDI/MDIX |
| Rețea media | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) |
| Număr ventilatoare | Fanless |
| Alimentare Externă | External Power Adapter (Output: 53.5 VDC / 0.81 A) |
| Packet Forwarding Rate | 7.44 Mpps |
| Porturi (RJ45) PoE | • Standard: 802.3 af/at compliant • PoE Ports: Ports 1–4 • Power Supply: 40 W |
| Tabelă de Adrese MAC | 2K |
| Jumbo Frame | 16 KB |
| Capacitate switching | 10 Gbps |
| Dimensiuni (L x l x H) | 3.9×3.9×1.0 in (99.8×98×25 mm) |
| Consum maxim | • 4.12 W (220/50 Hz. no PD connected) • 47.5 W (220/50 Hz. with 40 W PD connected) |
| Max Heat Dissipation | • 14.05 BTU/h (no PD connected) • 161.98 BTU/h (with 40 W PD connected) |
| CARACTERISTICI SOFTWARE | |
|---|---|
| Caracteristici Avansate | • Compatible With IEEE 802.3af/at Compliant PDs • Mac Address Auto-Learning And Auto-Aging • IEEE 802.3x Flow Control • 802.1p/DSCP QoS • IGMP Snooping |
| Metodă de Transfer | Store-And-Forward |
| ALTELE | |
|---|---|
| Certificări | FCC, CE, RoHS |
| Conținut Pachet | • TL-SG1005LP • Power Adapter • Installation Guide |
| Mediu | • Operating Temperature: 0–40 ℃ (32–104 ℉); • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
