| CARACTERISTICI HARDWARE | |
|---|---|
| Interfață | • 9× 10/100/1000 Mbps RJ45 Ports • 1× 1000 Mbps Combo SFP/RJ45 Port • AUTO Negotiation • AUTO MDI/MDIX |
| Rețea media | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) |
| Număr ventilatoare | Fanless |
| Physical Security Lock | Yes |
| Alimentare Externă | External Power Adapter (Output: 53.5VDC / 2.43A) |
| Packet Forwarding Rate | 14.88 Mpps |
| Porturi (RJ45) PoE | • Standard: 802.3 af/at compliant • PoE Ports: Ports 1–8 • Power Supply: 123 W |
| Tabelă de Adrese MAC | 4K |
| Jumbo Frame | 16 KB |
| Capacitate switching | 20 Gbps |
| Dimensiuni (L x l x H) | 8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm) |
| Consum maxim | • 7.93 W (220V / 50Hz with no PD connected) • 141.40 W (220V / 50Hz with 123 W PD connected) |
| Max Heat Dissipation | • 27.04 BTU/h (220V / 50Hz with no PD connected) • 482.17 BTU/h (220V / 50Hz with 123 W PD connected) |
| CARACTERISTICI SOFTWARE | |
|---|---|
| Metodă de Transmisie | Store-And-Forward |
| Funcții Avansate | • Compatible With IEEE 802.3af/at Compliant PDs • Extend Mode Button (Ports 1–4, Up to 250 m PoE power supply and data transmission) • Priority Mode Button (Ports 1–2) • Isolation Mode Button (Ports 1–4 / 5-8) • PoE Auto Recovery (Ports 1-8) • Mac Address Auto-Learning and Auto-Aging • IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure for Half-Duplex Mode |
| ALTELE | |
|---|---|
| Certificări | FCC, CE, RoHS |
| Conținut Pachet | • TL-SG1210MP • Power Adapter • Installation Guide |
| Mediu | • Operating Temperature: 0–40 ℃ (32–104 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
