| CARACTERISTICI HARDWARE | |
|---|---|
| Standarde și Protocoale | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x |
| Interfață | 24 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) |
| Rețea media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m) |
| Număr ventilatoare | Fanless |
| Physical Security Lock | No |
| Alimentator | 100-240VAC, 50/60Hz |
| Consum Energie | Maximum: 13.1W (220V/50Hz) |
| Dimensiuni (L x l x H) | 17.3*7.1*1.7 in. (440*180*44 mm) |
| Montare | Rack Mountable |
| Consum maxim | 13.62W |
| Max Heat Dissipation | 46.44BTU/h |
| PERFORMANȚĂ | |
|---|---|
| Switching Capacity | 48Gbps |
| Packet Forwarding Rate | 35.7Mpps |
| Tabelă Adrese MAC | 8K |
| Jumbo Frame | 10KB |
| QoS | 802.1p/DSCP QoS* *Doar versiunile hardware V11 sau mai recente |
| Green Technology | Yes |
| Transfer Method | Store-and-Forward |
| ALTELE | |
|---|---|
| Certificări | FCC, CE, RoHS |
| Conținut Pachet | 24-Port Gigabit Rackmount Switch Power Cord Installation Guide Rackmount Kits Rubber Feet |
| Mediu | Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉); Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing |
